Application skills of electric impact drill in drilling special materials?

When it comes to drilling special materials, the electric impact drill proves to be an indispensable tool. Its unique combination of rotational and impact forces allows it to penetrate a wide range of tough and specialized substances efficiently. This article will delve deep into the application skills of electric impact drills in drilling special materials, exploring different brands, models, and the best practices for optimal performance.

1. Understanding Electric Impact Drills

An electric impact drill is a power tool that combines the functions of a traditional drill and a hammer. It operates by delivering rapid, repetitive impacts along with rotational motion. This dual-action mechanism generates a significant amount of force, enabling it to break through hard materials more effectively than a standard drill. The impact force is measured in impacts per minute (IPM), and the rotational speed is measured in revolutions per minute (RPM). Different models offer varying combinations of IPM and RPM, making them suitable for different types of materials and tasks.

1.1 Key Components of an Electric Impact Drill

  • Motor: The heart of the electric impact drill, the motor provides the power for both the rotation and the impact function. High – quality motors are designed to deliver consistent performance and have a longer lifespan.
  • Gearbox: The gearbox controls the speed and torque of the drill. It allows users to adjust the settings according to the material being drilled, ensuring optimal performance and minimizing the risk of damage to the tool or the material.
  • Chuck: The chuck is the part of the drill that holds the drill bit. It comes in different sizes and types, such as key – type and keyless chucks. Keyless chucks are more convenient as they allow for quick and easy bit changes without the need for a separate key.
  • Impact Mechanism: This is the component that generates the impact force. There are different types of impact mechanisms, such as mechanical and hydraulic, each with its own advantages and disadvantages.

2. Special Materials and Their Drilling Challenges

Special materials refer to substances that have unique physical and mechanical properties, making them more difficult to drill compared to common materials like wood or soft metals. These materials include concrete, brick, tile, stone, and various types of hard metals.

2.1 Concrete

Concrete is one of the most common special materials used in construction. It is a composite material made up of cement, sand, gravel, and water, and it can be extremely hard and dense. Drilling into concrete requires a high – impact force to break up the aggregate and penetrate the cement matrix. The main challenges in drilling concrete include bit wear, overheating, and the risk of the drill bit getting stuck.

2.2 Brick

Brick is another widely used building material. While it is not as hard as concrete, it still poses challenges due to its brittle nature. Drilling into brick requires a delicate balance of impact and rotation to prevent the brick from cracking or chipping. Different types of bricks, such as clay bricks and concrete bricks, have different hardness levels and drilling requirements.

2.3 Tile

Tile is often used for flooring and wall coverings. It comes in various materials, including ceramic, porcelain, and natural stone tiles. Drilling into tile requires a very precise and gentle approach to avoid cracking or shattering the tile. The smooth surface of the tile also makes it difficult for the drill bit to grip, increasing the risk of slippage.

2.4 Stone

Natural stone, such as granite, marble, and limestone, is used in a variety of applications, from countertops to decorative elements. Stone is extremely hard and abrasive, which can quickly wear out drill bits. Drilling into stone also requires careful planning to ensure accurate hole placement and to prevent damage to the stone’s surface.

2.5 Hard Metals

Hard metals, such as stainless steel, titanium, and high – carbon steel, are used in many industrial applications. These metals have high tensile strength and hardness, making them difficult to drill. Specialized drill bits and techniques are required to drill into hard metals without causing excessive heat, tool wear, or work – piece deformation.

3. Popular Electric Impact Drill Brands and Models

There are several well – known brands in the market that offer high – quality electric impact drills. Each brand has its own range of models, each with unique features and capabilities.

3.1 Bosch

  • Bosch 18V Cordless Impact Drill GDS18V – 500C: This cordless impact drill is powered by an 18V lithium – ion battery, providing long – lasting power and performance. It has a maximum torque of 500 Nm, making it suitable for heavy – duty tasks. The drill features a brushless motor, which offers longer tool life, increased efficiency, and reduced maintenance. It also has a 4 – mode operation system, including a high – torque mode for drilling into tough materials like concrete and metal, and a precision mode for more delicate tasks. The GDS18V – 500C comes with a keyless chuck for easy bit changes and an LED work light to illuminate the work area.
  • Bosch Professional GSB18V – 55 FC: This is a versatile cordless drill/driver with impact function. It has a compact and lightweight design, making it easy to handle in tight spaces. The drill is equipped with a 18V lithium – ion battery and a brushless motor, providing up to 50% more runtime compared to brushed motors. It offers a maximum torque of 55 Nm and has a two – speed gearbox, allowing users to adjust the speed according to the material and task. The GSB18V – 55 FC also features a FLEXIClick system, which enables quick and easy bit changes and allows the tool to be used in different configurations.

3.2 DeWalt

  • DeWalt DCD996P2 20V MAX XR Brushless 1/2″ Hammer Drill/Driver*: This powerful cordless drill is part of DeWalt’s XR series, which is known for its high – performance and long – lasting batteries. The drill is powered by a 20V MAX* lithium – ion battery and features a brushless motor, delivering increased efficiency and longer tool life. It has a maximum torque of 135 Nm and a three – speed transmission, allowing users to select the optimal speed for different materials. The DCD996P2 also comes with a 1/2″ ratcheting chuck for a secure grip on drill bits, and it has an LED work light with a 20 – second delay to provide illumination after the drill stops.
  • DeWalt D25303K 1 – inch SDS – Plus Rotary Hammer Drill: This corded rotary hammer drill is designed for heavy – duty applications, especially in concrete and masonry. It has a powerful 12 – amp motor that delivers 0 – 1,300 RPM and 0 – 4,800 BPM (blows per minute). The SDS – Plus chuck system allows for quick and easy bit changes, and it provides a secure hold on the drill bit. The D25303K also features a variable – speed trigger and a reverse function, making it suitable for a wide range of drilling and chiseling tasks.

3.3 Makita

  • Makita XPH14Z 18V LXT Lithium – Ion Brushless Cordless 1 – inch Hammer Driver – Drill: This cordless hammer drill is part of Makita’s LXT series, which offers long – lasting battery performance. It is powered by an 18V lithium – ion battery and features a brushless motor, providing increased efficiency and reduced maintenance. The drill has a maximum torque of 130 Nm and a two – speed transmission. It also comes with a 1 – inch keyless chuck and an LED work light with afterglow function. The XPH14Z has a compact and ergonomic design, making it comfortable to use for extended periods.
  • Makita HR2475 1 – inch Corded Rotary Hammer Drill: This corded rotary hammer drill is designed for professional use. It has a 11 – amp motor that delivers 0 – 1,300 RPM and 0 – 4,800 BPM. The drill features a SDS – Plus chuck system for easy bit changes and a variable – speed control dial, allowing users to adjust the speed according to the material. The HR2475 also has a vibration – absorbing handle, which reduces user fatigue during long – term use.

4. Application Skills for Drilling Special Materials

4.1 Selecting the Right Drill Bit

  • For Concrete: When drilling into concrete, carbide – tipped masonry bits are the best choice. These bits have a hard carbide tip that can withstand the abrasiveness of concrete. The size of the bit should be selected according to the diameter of the hole required. For larger holes, core drills can be used, which are designed to remove a cylindrical piece of concrete.
  • For Brick: Masonry bits are also suitable for drilling into brick. However, for softer bricks, a spade bit may be used. It is important to choose a bit with a sharp tip to prevent the brick from cracking.
  • For Tile: Specialized tile bits, such as carbide – tipped glass and tile bits, are required for drilling into tile. These bits have a pointed tip that can score the surface of the tile, reducing the risk of cracking. Diamond – tipped bits are also effective for drilling into hard tiles like porcelain.
  • For Stone: Diamond – tipped drill bits are the most commonly used for drilling into stone. These bits are extremely hard and can cut through the abrasive surface of stone. The choice of bit depends on the type and hardness of the stone.
  • For Hard Metals: High – speed steel (HSS) bits with a cobalt content are suitable for drilling into hard metals. Cobalt – enhanced HSS bits have better heat resistance and can withstand the high temperatures generated during drilling. For very hard metals, carbide – tipped bits may be required.

4.2 Preparing the Material

  • Marking the Hole Location: Before drilling, it is essential to mark the exact location of the hole on the material. Use a pencil or marker to make a clear mark. For more accurate hole placement, a center punch can be used to create a small indentation at the mark, which helps to prevent the drill bit from wandering.
  • Securing the Material: Ensure that the material is firmly secured in place to prevent it from moving during drilling. For larger materials, clamps can be used to hold them down. For smaller materials, a vise or a workbench with a clamping mechanism can be used. This not only helps to ensure accurate hole placement but also reduces the risk of accidents.

4.3 Setting the Right Drill Settings

  • Impact and Rotation Settings: For hard materials like concrete and stone, a high – impact and low – rotation setting is usually recommended. This allows the drill to break up the material more effectively. For softer materials like tile and brick, a lower impact and higher rotation setting may be more suitable to prevent cracking and chipping.
  • Speed Settings: Adjust the speed of the drill according to the material. For example, when drilling into metal, a lower speed is required to prevent overheating and tool wear. When drilling into wood or plastic, a higher speed can be used for faster drilling.

4.4 Drilling Technique

  • Starting the Hole: When starting to drill, apply gentle pressure on the drill and start with a slow speed. This helps the drill bit to bite into the material and prevents it from slipping. Once the bit has made a small indentation, gradually increase the speed and pressure.
  • Drilling at the Right Angle: Ensure that the drill is held perpendicular to the surface of the material to create a straight hole. Using a level or a guide can help to maintain the correct angle.
  • Taking Breaks: When drilling into hard materials, it is important to take regular breaks to prevent the drill bit from overheating. Overheating can cause the bit to wear out quickly and may also damage the material.

4.5 Cooling and Lubrication

  • For Metal Drilling: When drilling into metals, especially hard metals, using a lubricant such as cutting oil can help to reduce friction, prevent overheating, and extend the life of the drill bit. Apply the lubricant to the drill bit and the work – piece during drilling.
  • For Other Materials: For materials like concrete and stone, water can be used as a coolant. Spray water on the drill bit and the drilling area to keep the temperature down and prevent the bit from wearing out too quickly.

5. Maintenance and Safety Precautions

5.1 Maintenance

  • Cleaning: After each use, clean the drill and the drill bits to remove any debris or dust. Use a brush or compressed air to clean the drill’s vents and the chuck. For drill bits, use a wire brush to remove any material stuck to the bit.
  • Lubrication: Regularly lubricate the moving parts of the drill, such as the gearbox and the chuck. Use a high – quality lubricant recommended by the manufacturer.
  • Inspection: Periodically inspect the drill for any signs of damage, such as cracks in the housing, worn – out brushes (if applicable), or loose parts. If any damage is detected, have the drill repaired or replaced immediately.

5.2 Safety Precautions

  • Personal Protective Equipment (PPE): Always wear appropriate PPE, such as safety glasses, gloves, and ear protection. Safety glasses protect your eyes from flying debris, gloves provide a better grip and protect your hands from cuts and abrasions, and ear protection reduces the risk of hearing damage from the noise of the drill.
  • Electrical Safety: If using a corded drill, ensure that the power cord is in good condition and that the drill is properly grounded. Avoid using the drill in wet or damp conditions to prevent the risk of electric shock.
  • Proper Handling: Hold the drill firmly with both hands and keep your body in a stable position. Do not force the drill or apply excessive pressure, as this can cause the drill to kick back or the bit to break.



In conclusion, electric impact drills are powerful tools that can be used effectively for drilling special materials. By understanding the different types of special materials, choosing the right drill bit, preparing the material properly, setting the correct drill settings, and following the right drilling techniques, maintenance, and safety precautions, users can achieve excellent results. The availability of various high – quality brands and models, such as Bosch, DeWalt, and Makita, provides a wide range of options to meet different needs and budgets. Whether for professional construction work or DIY projects, mastering the application skills of electric impact drills in drilling special materials is essential for successful and efficient work. If you have any specific requirements or further questions regarding electric impact drills and their use with special materials, feel free to explore more detailed product specifications or consult with experts in the field.
